Delivered Apparatus

FEATURES:

• Spartan MFD Metro Star
• 450 HP Cummins L9
• Allison 3000 EVS Automatic Transmission
• Six (6) Person cab with five (5) SCBA seats
• 24” Front Bumper Extension with one (1) 1 ½” Preconnect and Center Hose Well
• Progressive Dynamics Battery Conditioner with VIAIR Auxiliary Compressor
• Heavy Duty Aluminum Subframe & Aluminum Body
• ROM Series IV Satin Finish Roll Up Doors
• 1000 Gallon Poly Water Tank
• Top Control Pump Module
• Hale QMAX-XS 150 1500 GPM Split Shaft Pump
• One (1) 5” Front Suction
• Two (2) 6” Suctions, one (1) each side
• One (1) 2 ½” Gated Suction, Left Side
• Four (4) 2 ½” Discharges, Two (2) Left, One (1) Right, & One (1) Rear
• One (1) 3” Discharge, Right Side
• One (1) 3” Fixed Monitor Piping Over Pump Compartment
• Two (2) 1 ½” Cartridge Lay Preconnects
• Low Hose Bed with One (1) Divider
• Electronically Controlled Ladder Rack
• Suction Hoses, Pike Poles and Attic Ladder Storage Through the Tank
• Aluminum Rub Rails with LED Ground Lights and LED Warning Lights
• Duradeck Tile on floors of the compartments
• Whelen LED Warning Light Package
• Federal Q2B mechanical Siren, front bumper
• Fire Tech 12 Volt Scene Lights Package
• Diamond Grade Chevron Striping, Rear
• 9’ 10” Overall Height
• 34’ Overall Length
• 208” Wheelbase
• 154” Cab to Axle
• 20,000 FAWR
• 27,000 RAWR
• 47,000 GVWR
