Delivered Apparatus

FEATURES:

• International HV607 Crew Cab Chassis
• Cummins L9 360 HP Diesel Engine
• Allison 3000 EVS Transmission
• Heavy Duty Stainless Steel Body with Stainless Steel Subframe
• Rear Mount Pumping System
• Waterous CXVK 1500 GPM Rear Mount Pump
• Trident Air Primer
• Diesel Fired Pump Heater
• Rear Mount Pump Operator’s Panel Behind Roll Up Door
• FRC Pump Boss Pressure Governor Monitoring System
• FRC Tankvision Water Tank Level Gauge
• One (1) 6” Intake, Rear
• One (1) 2½” Gated Intake, Rear
• Two (2) 2½” Discharges, Rear
• One (1) 3” Discharge Adapted to 2½” MNST, Rear
• One (1) 3” Deck Gun Discharge Rear Over Pump in Hose Bed Center
• FoamPro 1600 Foam System with 20 Gallon Foam Tank
• One (1) 1½” and One (1) 2½” Crosslay Preconnects – Front Bumper
• ROM Roll-Up Doors
• Two (2) Dual Wheel Well Air Bottle Compartments, One (1) Each Side
• Two (2) Triple Wheel Well Air Bottle Compartments, One (1) Each Side
• Zico Overhead Hydraulic Ladder Rack, Dual Arm
• Suction Hose Storage for Two (2) lengths Hose, Left Side Upper
• 1000 Gallon Poly Tank
• 12 Volt Electrical System with NFPA Compliant Warning Light Package
• Whelen LED Warning Light Package
• Progressive Dynamics Battery Charger wit Viar Compressor
• Kussmaul 20 Amp Super Auto-Eject 120V Shoreline Connection, Left Side
• Kussmaul Auto Air Eject
• Whelen 200W Siren and 100W Speaker
• Two (2) FireTech HiViz 40″ LED Scene Light Bars, One (1) Each Side
• One (1) FireTech HiViz 21″ LED Scene Light Bars, Rear Center
• One (1) FireTech HiViz 21” LED Brow Light
• One (1) 10’ Attic Ladder, One (1) 14’ Roof Ladder with Hooks, One (1) 24’ 2-Section Ladder, and Two (2) 10’ Lengths of 6” Suction Hose
• 10’ Overall Height
• 31’ 8” Overall Length
• 201” Wheelbase
• 89.9” Cab to Axle
• 16,000 FAWR
• 30,000 RAWR
• 46,000 GVWR
