Delivered Apparatus

FEATURES:

• Ford F-550 XL 4-Door DRW 4×4 Chassis
• Ford 6.7L V8, 330-HP Diesel Engine
• Ford TorqShift 6-speed Automatic Transmission
• Heavy Duty Stainless steel Body and Sub-Frame
• ROM painted Roll Up Doors
• Front and Rear Reese type hitches with electrical connections
• Two (2) Tie off points with electrical connections, one (1) each side of body
• One (1) Warn 9000-lb Winch
• 300-Gallon Poly Tank
• Hale DSD 1250-GPM Pump with left side pump operator’s panel
• Three (3) 2 ½” Discharges, two (2) left side and one (1) rear
• One (1) 2 ½” Preconnect, front of hose bed left side
• Two (2) 1 ½” Mattydale Preconnects, across top of body
• One (1) Electric Booster reel with 200-ft of 1” hose
• EMS compartment between rear cab seats
• Two (2) Fire extinguisher brackets on roll out tray, right side
• Ladder and Pike pole storage compartment, upper right side
• Backboard storage compartment, upper left side
• Two (2) Air Bottle storage compartments, one (1) each side wheel well
• One (1) Akron Electric Cord reel with 150-ft of 10/3 cord
• Progressive Dynamics on-board battery charger with Viair air compressor
• Kussmaul Super Auto Eject 120-volt shoreline connection
• Audiovox Back-up Camera system with 7” color monitor
• Floor mounted console for emergency switches with map/binder storage, cab
• Whelen Electronic Siren with 100-watt Whelen speaker
• Federal Q2B pedestal mount Siren, front bumper
• One (1) 12” Chrome Bell electrically controlled, front bumper
• Whelen LED Scene Light Package and Unity spot lights
• Whelen LED Warning Light Package
• Diamond Grade Chevron pattern striping, rear
• 9’ 1” Overall height
• 28’ 10” Overall length
• 203” Wheelbase
• 84” Cab to Axle
• 7,500 FAWR
• 14,706 RAWR
• 19,500 GVWR
