CUSTOM SIDE CONTROL PUMPER #2327

BRAIDWOOD FIRE PROTECTION DISTRICT - BRAIDWOOD, ILLINOIS

• Spartan Metro Star ELFD 10” raised roof Chassis
• Cummins L9, 450-HP Diesel Engine
• Allison 3000 EVS Automatic Transmission
• Heavy Duty Aluminum Body w/ Galvanized Sub-Frame
• ROM painted Roll Up compartment Doors
• 28” Front Bumper Extension, Customized with rescue tools and CMW reels
• Four (4) Person cab seating with three (3) SCBA seats
• EMS compartment and Map Box, chassis cab
• Stokes Basket/backboard rack and Pike pole storage, chassis cab
• 1000-Gallon Poly Tank with 10-gallon and 20 gallon foam tanks
• One (1) 2 ½” ball valve Tank fill, rear
• Waterous CSU 1500-GPM Pump w/ left side pump controls
• Four (4) 2 ½” Discharges, two (2) left, one (1) right side and one (1) rear
• Two (2) 3” Discharges, one (1) right side and one (1) over pump for Deck gun
• One (1) TFT Hurricane wireless remote control monitor package
• Two (2) 2 ½” Gated Suction, one (1) each side
• Two (2) 2 ½” Preconnects, One (1) front bumper and one (1) front of hose bed
• Two (2) 1 ½” Mattydale preconnects, across top of body
• Williams around the pump Class A or B foam proportioner
• Two (2) Triple bottle Air bottle compartments, one (1) each side wheel well
• One (1) Fire Extinguisher compartment, right side rear wheel well
• Ladder and pike pole storage, right side vertical with rear access
• Two (2) Suction hose storage gutters, one (1) each side
• Sure-Grip Stainless steel top access ladder, rear mounted
• Kussmaul on-board battery charger w/ air compressor
• Federal Q2B mechanical Siren, recess mounted front bumper
• One (1) Harrison 10,000-watt hydraulic Generator with 120-volt system
• Two (2) Electric cord reels w/ 150-ft of 10/4 cord and junction boxes
• Whelen LED Warning Light and Scene Light Packages
• Chevron pattern diamond grade “SceneDOTS”, rear
• 10’ 8” Overall height
• 33’ 10” Overall length
• 202” Wheelbase
• 128” Cab to Axle
• 21,500 FAWR
• 27,000 RAWR
• 48,500 GVWR

Year: 2018
Make: Alexis Fire Equipment
Model: Pumper
Chassis: Custom
Body Style: Side Control Pumper
Pump Size: 1500
Tank Size: 1000
Feature: Interior Mount Ladder
Exterior Color: Red with White
New Delivery: New Delivery
