Delivered Apparatus

FEATURES:

• Spartan FC-94 MFD 10” Raised Roof Chassis
• Cummins L9 450 HP Diesel Engine
• Allison 3000 EVS Automatic Transmission
• Heavy Duty Aluminum Body and Sub-Frame
• Four (4) Person Cab
• Side Control Stainless-Steel Pump Module
• Hale DSD 150 Single Stage Split-Shaft 1500 GPM Pump
• Trident Air Prime System
• FRC Pump Boss Pressure Governor & Monitoring System
• Two (2) 6” Intakes, One (1) Each Side
• One (1) 2½” Gated Intake, Left Side
• One (1) 6″ Low Level Strainer with 1½” Water Transfer Port
• One (1) 4” FirePrograms Tank Fill adapted to 4” Storz, Rear
• One (1) 2½” Discharge, Left Side
• One (1) 3” Discharge adapted to 5” Storz, Right Side
• One (1) 4” Discharge adapted to 4” Storz, Right Side
• Two (2) 1½”, One (1) 2½”, LA Style Foam Capable Preconnects, Pump Module
• FoamPro 2001 Foam System with 30-Gallon Tank
• Foam Capable Discharges, Two (2) 1½ Crosslay Preconnects, One (1) 2½” Crosslay Preconnect
• 2000-Gallon Wetside Poly Tank with Aluminum Side Panels
• 2100-Gallon Aluminum Folding Tank on Zico Hydraulic Bracket, Right Side
• Ladder Storage Capacity: One (1) 14’ Roof Ladder with Hooks, One 24’ (1) Two Section Ladder, Rear Through Tank
• Two (2) 10’ x 6” Hard Suction Hoses, Above Left Compartments
• Hose Bed with One (1) Divider, LED Lighting, Aluminum Treadplate Cover
• One (1) 10” Newton Stainless-Steel Electric Swivel Dump, Rear
• Three (3) Folding Steps, Rear
• EMS Compartment in Cab with Top Strap for Zoll Autopulse and 120V Power Strip
• ROM Locking Roll-Up Doors
• Aluminum Rub Rails with LED Warning Lights & LED Undercarriage Lights
• Four (4) 250# Roll Out Trays, One (1) Each, L1, L3, R1, R3 Compartments
• ChanL PanL on Upper Rear Wall, L1, L3, R1, R2, R3 Compartments
• Four (4) Walk-Away Air Pak Brackets, L2 Compartment
• Two (2) Dual Wheel Well Air Bottle Compartments, One (1) Each Side Ahead of Rear Wheel Well
• One (1) Dual Fire Extinguisher Compartment, Right Side Behind Wheel Well
• Kussmaul 20 Amp Super Auto-Eject 120V Shoreline Connection
• Whelen Warning Light Package
• Whelen and FireTech Scene Lights
• One (1) GoLight Remote Controlled LED Spotlight
• One (1) FireTech Brow Light
• Whelen LED Arrow Stick
• Whelen LED Tank Gauge, One (1) Each Side, One (1) Rear
• Electric Siren with 100 Watt Speaker
• Diamond Grade Chevron Striping
• Overall height 10’ 2”
• Overall length 32’
• Wheelbase 201”
• Cab to Axle 147”
• 20,000 FAWR
• 33,000 RAWR
• 53,000 GVWR
