Delivered Apparatus

FEATURES:

• Spartan FC-94 MFD Chassis with 10” Raised Roof
• Cummins 450 HP L9 Engine
• Allison 3000 EVS Automatic Transmission
• Heavy Duty 3/16 Aluminum Body and Subframe
• Intermediate Pump Module
• One (1) Free Floating Hose Well, Right Side Running Board
• MAC1 1500GPM Single Stage Pump
• Trident 2-Location Air Prime System
• FRC Pump Boss Pressure Governor
• FRC TankVision Water Tank Level Gauge with Three (3) FRC MaxVision Lights
• Two (2) 6” Intakes, One (1) Each Side and One (1) 5” Front Intake with 6” NST Swivel
• One (1) 2½” Gated Intake, Left Side
• Two (2) 2½” Discharges Left Side and One (1) 2½” Discharge Right Side
• One (1) 3” Discharge Adapted to 4” Storz, Right Side
• One (1) 3” Discharge, Rear
• One (1) 3” Discharge in Dunnage for Deck Gun
• One (1) 1½” and One (1) 2½” Mattydale Preconnect with Deadlay Hose Bed
• One (1) 1½” Bumper Extension Preconnect
• One (1) Booster Reel with 100’ of 1” Booster Hose, Dunnage Area
• Three (3) Dual Wheel Well Air Bottle Compartment, One (1) Left and Two (2) Right
• ROM Roll-Up Doors
• Zico Hydraulic Folding Tank Bracket, Right Side
• Ladder Storage Through the Tank, Left Side
• 1800 Gallon Poly Wetside Tank with Wetside Hose Bed & Front Fill Tower
• Two (2) 4” Stortz FirePrograms Tank Fills, Rear
• One (1) 10” Newton Stainless Steel Manual Swivel Dump, Rear
• 12 Volt Electrical System with NFPA Compliant Warning Light Package
• Kussmaul Auto Charge LPC40 Battery Charger with 12V Pump in Cab
• Kussmaul 20 Amp Super Auto-Eject 120V Shoreline Connection, Left Side of Cab
• Whelen LED Warning Light Package with Whelen 200W Siren with 100W Speaker
• Federal Q2B Pedestal Mounted Siren Left Side
• Two (2) FireTech HiViz 40″ LED Scene Light Bars, One (1) Each Side
• One (1) FireTech HiViz 21″ LED Scene Light Bars, Rear Center
• One (1) FireTech HiViz 72” LED Brow Light
• One (1) 10’ Attic Ladder, One (1) 14’ Roof Ladder with Hooks, One (1) 24’ 2-Section Ladder, One (1) 2100 Gallon Fol-Da-Tank and Two (2) 10’ Lengths of 6” Suction Hose
• 9’-10” Overall Height
• 33’-1” Overall Length
• 193” Wheelbase
• 139” Cab to Axle
• 21,500 FAWR
• 31,500 RAWR
• 53,000 GVWR
