Delivered Apparatus

FEATURES:

• Spartan Metro Star EMFD Flat Roof Chassis
• Cummins 450 HP L9 Engine
• Allison 3000 EVS Automatic Transmission
• Heavy Duty Stainless Steel Body and Stainless Steel Subframe
• Stainless Steel Side Control Pump Module
• Free Floating Hose Well Left Running Board
• Hale QMAX-XS 1500GPM Single Stage Pump
• SAM Water Control System with all Electric Valves
• Class 1 ITL Water Tank Guage with Whelen PSTANK2 Strip Lite at Rear
• Two (2) 6” Intakes, One (1) Each Side with Hale MIV Valves
• One (1) 2½” Gated Intake, Each Side
• Two (2) 2½” Discharges Left Side and Two (2) 2½” Discharge Right Side
• Four (4) 2½” Discharges Rear
• One (1) 4” Discharge Adapted to 4” Storz, Right Side
• One (1) 3” Discharge in Pump Module Dunnage for Deck Gun
• Hale SmartFOAM 2.1A Foam System with 20 Gallon Tank
• One (1) 1½” Bumper Extension Preconnect
• One (1) Booster Reel Dunnage Area with 150’ of 1” hose
• Three (3) Triple Wheel Well Air Bottle Compartment, One (1) Left and Two (2) Right
• ROM Painted Roll-Up Doors
• Ladder Storage Rack Right Side
• Hard Suction Hose Storage One (1) Each Side
• 1000 Gallon Poly Tank
• 12 Volt Electrical System with NFPA Compliant Warning Light Package
• Kussmaul Auto Charge LPC40 Battery Charger with Blue Sea 12V Pump in Cab
• Blue Sea 20 Amp Super Auto-Eject 120V Shoreline Connection, Left Side of Cab
• Whelen LED Warning Light Package with Ion LED Arrow Stick Rear
• Whelen Cencom CORE Warning Light Control System
• Federal Q2B Recess Mounted Siren Left Side
• Two (2) FireTech HiViz 27″ LED Scene Light Bars, One (1) Each Side
• Twi (2) FireTech HiViz 8″ LED Scene Light Bars, Rear One (1) Each Side
• One (1) FireTech HiViz 72” LED Brow Light
• One (1) 10’ Attic Ladder, One (1) 14’ Roof Ladder with Hooks, One (1) 24’ 2-Section Ladder, and Two (2) 10’ Lengths of 6” Suction Hose
• 10’ Overall Height
• 33’-9” Overall Length
• 205” Wheelbase
• 145” Cab to Axle
• 21,500 FAWR
• 27,000 RAWR
• 48,500 GVWR
