• Spartan Gladiator MFD (medium four door) Tandem Chassis
• Detroit Series 60, 490-HP Diesel Engine
• Allison 4000 EVS Automatic Transmission
• Heavy Duty 3/16″ Aluminum Body
• 104-Foot Four-Section Rear-Mount Platform
• Breathing Air System to the end of the Platform
• UPF 300-Gallon Rectangular Poly Tank
• Waterous CMU, 1500-GPM Pump with left side controls
• Three (3) 2 ½” Discharges, two (2) left and one (1) right side
• One (1) 3″ Discharge, right side and One (1) 4″ Discharge feeding the waterway
• Two (2) 1 ½” and one (1) 2 ½” Cartridge Lay Preconnects
• One (1) 2 ½” Gated Pre-connect Discharge, platform basket
• Akron Remote Controlled Electric monitor at the end of platform
• Tool Board for two (2) long tools and two (2) axes, between rear seats in cab
• Box Style [...]

• HME 1871 MFD Flat Roof Tandem Chassis
• Detroit Diesel 515-HP Series 60 Diesel Engine
• Allison 4000 EVS Automatic Transmission
• Heavy Duty 3/16” Aluminum Body
• ROM Roll Up Doors
• UPF 300-Gallon Poly Tank
• Hale QMAX200, 2000-GPM Midship Pump
• Left Side Control Pump Operator’s panel
• 104-Foot, Four Section Rear-Mount Platform
• Remote controlled Electric Monitor at end of platform
• Breathing Air System to end of platform
• Three (3) 2 ½” Discharges, Two (2) left side and one (1) right side
• Two (2) 4” Discharges, One (1) right side and one (1) feeding waterway
• One (1) 2 ½” Gated Suction, left side
• One (1) 1 ¾” Mattydale deadlay hose bed, pump module area
• Three (3) Cartridge Lay Preconnects, two (2) 1 ½” and one (1) 2 ½”
[...]

• Spartan Gladiator LFD 10” raised roof Chassis
• Caterpillar C13, 525-HP Diesel Engine
• Allison 4000 EVS Automatic Transmission
• Heavy Duty 3/16” Aluminum Body with ROM Roll Up and box style doors
• 101-Foot 3-Section Rear Mount Platform
• Akron Remote controlled Electric Monitors at end of platform
• Breathing Air system to end of platform
• 450-gallon Poly Tank
• Hale QMAX 200, 2000-GPM Pump
• Two (2) 2 ½” Discharges, one (1) each side
• Three (3) 4” Discharges, one (1) each side and one (1) rear
• Two (2) 2 ½” Gated Suction, one (1) each side
• One (1) 2 ½” and two 1 ¾” Cartridge Lay Preconnects
• One (1) 2 ½” Preconnect, front bumper extension
• One (1) Mattydale deadlay for 400-ft of 3” hose
• Three (3) single and two (2) [...]

• HME Spectr MFDxL Tandem Chassis
• Cummins ISM 500, 500-HP Diesel Engine
• Allison 4000 EVS Automatic Transmission
• Heavy Duty 3/16” Aluminum Body with box style and ROM roll up doors
• 100-ft Four Section Rear Mount Ladder
• Akron Remote controlled Electric Monitor at end of the ladder
• Breathing Air System to end of ladder
• 300-Gallon Poly Tank
• Hale QMAX 150, 1500-GPM Pump with left side operator’s panel
• Three (3) 2 ½” Discharges, Two (2) left side and one (1) right side
• One (1) 3” Discharge, right side and one (1) 4” Discharge feeding waterway
• One (1) 2 ½” Gated Suction, left side
• One (1) 2 ½” Mattydale Preconnect and two (2) 1 ½” Cartridge Lay Preconnects
• 21” Front bumper extension
• Three (3) Air bottle compartments, one (1) single [...]

• HME Spectr MFD xL Chassis
• Cummins ISM, 500-HP Diesel Engine
• Allison 4000EVS Automatic Transmission
• Heavy Duty 3/16” Aluminum Body with ROM roll up and box style doors
• 300-Gallon Poly Tank
• Hale QMAX150, 1500-GPM Pump with left side pump operator’s panel
• Four (4) 2 ½” Discharges, two (2) each side
• One (1) 4” Discharge feeding waterway
• One (1) 2 ½” Gated Suction, left side
• Two (2) 1 ½” and one (1) 2 ½” Cartridge Lay Preconnects, front of body
• Mattydale Dead Lay hose bed, top of body
• 24” Front Bumper Extension with 1 ½” Preconnect and center hose well
• One (1) 5” Front Suction with electric control at pump panel
• 104-Foot, Four Section Rear-Mount Platform
• Akron Remote controlled Electric Monitors at end of platform
• Breathing [...]

• HME Spectr LFD Chassis
• Cummins ISM500, 500-HP Diesel Engine
• Allison 4000EVS Automatic Transmission
• Heavy Duty 3/16” Aluminum Body with ROM Roll Up Doors
• 300-Gallon Poly Tank
• Hale QMAX200, 2000-GPM Pump with Left side Pump operator’s controls
• Four (4) 2 ½” Discharges, two (2) each side
• Two (2) 4” Discharges, one (1) right side and one (1) feeding waterway
• One (1) 2 ½” Gated Suction, left side
• Two (2) 1 ½” and one (1) 2 ½” Cartridge Lay Preconnects, front of body
• One (1) 2 ½” Preconnect at platform and one (1) Deadlay Hosebed over pump
• Akron Remote controlled Electric monitor at end of platform
• Two (2) EMS compartments with roll up door and two (2) shelves each, cab
• Zico Quik Ladder for turntable access
• Two (2) [...]

• Spartan Metro Star MFD flat roof Chassis
• Cummins ISL9, 450-HP Diesel Engine
• Allison 3000 EVS Automatic Transmission
• Heavy Duty 3/16” Aluminum Body with Amdor brand Roll Up Doors
• 24” Front Bumper extension with 1 ½” Preconnect and center hosewell
• 750-Gallon Poly Tank
• One (1) 2 ½” Fireman’s Friend Tank fill, rear
• Waterous CXVC, 1500-GPM Pump with left side pump operator’s panel
• Four (4) 2 ½” Discharges, two (2) left side, one (1) right side and one (1) hose bed
• One (1) 3” Discharge, right side
• One (1) 4” Discharge feeding aerial waterway
• Two (2) 1 ½” Mattydale Preconnects, across top of pump module
• One (1) 2 ½” Gated Suction, left side
• One (1) 5” front suction
• Akron remote controlled Electric monitor at end of ladder
[...]

• Spartan Gladiator ELFD flat roof Chassis
• Cummins ISX12, 450-HP Diesel Engine
• Allison 4000 EVS Automatic Transmission
• Heavy Duty 3/16” Aluminum Body with Amdor brand Roll Up Doors
• 500-Gallon Poly Tank
• Waterous CSU 1500-GPM Pump with left side operator’s panel
• Four (4) 2 ½” Discharges, two (2) each side
• Two (2) 4” Discharges, one (1) right side and one (1) rear feeding waterway
• Akron remote controlled electric monitor at end of ladder
• One (1) 2 ½” Gated Suction, left side
• One (1) 2 ½” Mattydale Preconnect, top of pump module
• 28” Front bumper extension with two (2) 1 ½” Preconnects
• EMS cabinet with roll up doors and shelves, cab interior rear wall
• Free floating running board hose well, right side
• Four (4) Dual bottle Air Bottle compartments, [...]

• Spartan Metro Star LFD 10″ raised roof Chassis
• Cummins ISL9, 400-HP Diesel Engine
• Allison 3000 EVS Automatic Transmission
• Five (5) man cab seating with four (4) SCBA seats
• Heavy Duty 3/16″ Aluminum Body with ROM roll up doors
• 1000-Gallon Poly Tank
• One (1) 2 ½” Fireman’s Friend tank fill, rear
• Waterous CXS. 1500-GPM Pump with top operator’s controls
• Three (3) 2 ½” Discharges, two (2) left and one (1) right side
• Two (2) 3″ Discharges, one (1) right side and one (1) over pump for Deck gun
• One (1) TFT Crossfire monitor with TFT electric extend-a-gun
• One (1) 2 ½” Gated Suction, left side
• One (1) 2 ½” Preconnect, front of hosebed
• Two (2) 1 ½” Cartridge lay preconnects, front of body
• 24″ Front Bumper extension [...]
