TOP MOUNT MAP PUMPER #2416
MOORLAND TOWNSHIP - RAVENNA, MICHIGAN- February 1, 2022
- Not categorized
- Posted by R_Admin
- Comments Off on TOP MOUNT MAP PUMPER #2416
- Spartan MFD Metro Star
- 450 HP Cummins L9
- Allison 3000 EVS Automatic Transmission
- Six (6) Person cab with five (5) SCBA seats
- 24” Front Bumper Extension with one (1) 1 ½” Preconnect and Center Hose Well
- Progressive Dynamics Battery Conditioner with VIAIR Auxiliary Compressor
- Heavy Duty Aluminum Subframe & Aluminum Body
- ROM Series IV Satin Finish Roll Up Doors
- 1000 Gallon Poly Water Tank
- Top Control Pump Module
- Hale QMAX-XS 150 1500 GPM Split Shaft Pump
- One (1) 5” Front Suction
- Two (2) 6” Suctions, one (1) each side
- One (1) 2 ½” Gated Suction, Left Side
- Four (4) 2 ½” Discharges, Two (2) Left, One (1) Right, & One (1) Rear
- One (1) 3” Discharge, Right Side
- One (1) 3” Fixed Monitor Piping Over Pump Compartment
- Two (2) 1 ½” Cartridge Lay Preconnects
- Low Hose Bed with One (1) Divider
- Electronically Controlled Ladder Rack
- Suction Hoses, Pike Poles and Attic Ladder Storage [...]
12’ QUICK RESPONSE UTILITY RESCUE #S773
IOWA COUNTY RESCUE - MARENGO, IOWA- February 1, 2022
- Not categorized
- Posted by R_Admin
- Comments Off on 12’ QUICK RESPONSE UTILITY RESCUE #S773
- Chevrolet Silverado MD 4WD Crew Cab
- Duramax 6.6L Turbo-Diesel
- Allison 2700 EVS Automatic Transmission
- Heavy Duty 14 Gauge Stainless-Steel Body and Subframe
- ROM Satin Finish Roll-Up Doors
- 100 Gallon Poly Tank with 2 ½ Gallon Foam Tank
- One (1) 1 ½” direct tank fill with a 1 ½” x ¾ GHT adapter
- High-pressure, low-flow triplex 8 GPM Cat pump 56G1
- One (1) 8 HP Honda GX 270 Engine
- High Pressure Electric Reel with 100’ ½” hose
- Two (2) Air Bottle Storage Compartments, right side
- Stainless Steel Sure-Grip Top Access Ladder, rear mounted
- One (1) Strokes Basket and Three (3) Backboard Storage Rack
- Two (2) Aluminum PAC Vertical Pull Out Boards, left side
- Floor Mounted Console for Emergency Switches, Cab
- Progressive Dynamics on-board Battery Charger
- Kussmaul Super Auto Eject and 120-Volt Shoreline
- Whelen Warning Light Package and Scene Light Package
- One (1) Whelen Electric Siren & 100 W Speaker
- One (1) Audiovox Back-up Camera [...]
10’ RESPONSE ONE / SKID UNIT #S779
GARNER FIRE DEPARTMENT - GARNER, IOWA- December 17, 2021
- Not categorized
- Posted by R_Admin
- Comments Off on 10’ RESPONSE ONE / SKID UNIT #S779
- Ford F550 Crew Cab 4×4 Chassis
- 7.3L V8 Gas Engine
- Automatic TorqShift 10-speed Transmission
- Black n-Fab Crew Steps
- Black Buckstop Outback with Hidden Winch Mount and Receiver
- Darley 2BE Direct Drive Pump
- Discharges-One (1) 2.5”, One (1) 1.5”, & Hannay Electric Booster Reel
- Akron Model 3462 Forestry Bumper Turret
- 300 Gallon Poly Tank
- FRC Water Level gauge
- 10’ Response One -Stainless Steel Body
- Sub-Frame- Heavy Duty Stainless Steel
- Two (2) Rear Tow Eyes
- Two (2) Wheel Well SCBA Compartments
- ROM Painted Roll Up Doors
- Assortment of Shelves, Roll Out Trays, Mounted Fire Extinguishers, Walk Away Air Pack Brackets, Backer Board for Tool Mounting, etc
- Customized Shelf behind Center Console for Mounting Equipment
- LED Krystal-Lite Strip Lights for Compartments
- Floor Mounted Console for Emergency Switches
- Progressive Dynamics PD2140 Battery Charger with Kussmaul Auto Eject
- Whelen M Series Warning Light Package
- Whelen Siren and Speaker
- Whelen TAM65 LED Arrow Stick
- LED Rub Rail Warning Lights [...]
2000 GALLON TANKER #2412
URSA FIRE PROTECTION DISTRICT - URSA, ILLINOIS- December 17, 2021
- Not categorized
- Posted by R_Admin
- Comments Off on 2000 GALLON TANKER #2412
FEATURES:
- Freightliner M2 106 Conventional Chassis
- Cummins L9 350 HP Diesel Engine
- Allison 3000 EVS Transmission
- Heavy-Duty 304 Stainless-Steel Body & Sub Frame
- Intermediate Stainless Steel Pump Module
- Darley PSM 1500 GPM Split Shaft Pump
- Trident 3 Barrel Air Primer
- FRC Pump Boss Pressure Governor
- Stainless Steel Manifold & Plumbing
- Discharges- One (1) 2.5” Left, One (1) 2.5” Rear, & One (1) 3” Right
- Mattydale Preconnects-One (1) 1.5” & One (1) 2.5”
- Fixed Monitor Piping
- One (1) 2.5” Gated Suction Intake, Left Side
- Akron Valves
- Robinson Statin Finish Roll Up Doors
- 2000 Gallon Poly Tank
- One (1) 2.5” Fire Programs Fill
- Newton Stainless Steel Swivel Dump with Extension
- Progressive Dynamics PD2140 Battery Charger with Kussmaul Auto Eject
- Floor Mounted Console for Emergency Switches
- Whelen Warning Light Package
- Rub Rail LED Warning Lights & LED Ground Lights
- Whelen Siren & Siren Speaker
- Fold Da Tank Storage Passenger Side Compartment Top
- Suction Hose Storage Driver’s Side [...]
3000-GALLON TANKER #2438
CLARK COUNTY FIRE DEPARTMENT - LAS VEGAS, NEVADA- December 17, 2021
- Not categorized
- Posted by R_Admin
- Comments Off on 3000-GALLON TANKER #2438
- Freightliner M2 106 Tandem 2-Door Chassis
- Cummins L9, 350-HP Diesel Engine
- Allison 3000 EVS Automatic Transmission
- Heavy Duty Stainless Steel Body and Sub-frame
- ROM Roll Up Doors
- 3000-Gallon Wet side Poly Tank
- One (1) 2 ½” Fire Programs Tank fill, rear
- One (1) Newton 10” square manual swivel dump with 36” extension
- Hale DSD 150 Split Shaft 1500 GPM Pump
- Left side intermediate pump operator’s panel
- Stainless Steel Manifold & Plumbing
- Three (3) 2 ½” Discharges, two (2) left side and one (1) right side
- One (1) 3” Discharge with 5” Storz, right side
- One (1) 1 ½” and one (1) 2 ½” Mattydale Preconnects, behind cab
- One (1) 2 ½” Gated Suction, left side
- Folding Tank storage, right side compartment top
- Suction hose storage, left side compartment top
- Manual battery recharge shoreline connection
- Air coupling for external air compressor
- Floor mounted console for emergency switches, cab
- SCBA Bracket Mounted in Cab
- Whelen [...]
TOP CONTROL EQUALIZER PUMPER #2360
KEWANEE COMMUNITY FIRE PROTECTION DISTRICT - KEWANEE, ILLINOIS- November 30, 2021
- Not categorized
- Posted by R_Admin
- Comments Off on TOP CONTROL EQUALIZER PUMPER #2360
- International MV 607 Two Door Chassis
- Cummins L9 350 HP Diesel Engine
- Allison 3000 EVS Transmission
- Hale DSD 1250 GPM Pump
- Trident 3-Barrel Air Primer
- Two (2) Akron Model 7983 Revolution Butterfly Valves
- FRC Pump Boss Pressure Governor
- Stainless Steel Manifold and Plumbing
- Top Control Operator and Discharge Panels Incorporated in the Body
- Discharges-2.5” One (1) Left & One (1) Right, 3” Discharges-One (1) Right & One (1) Rear, Preconnects-Two (2) 1.5” Module
- One (1) 2.5” Gated Intake, Left Side
- 3” Fix Monitor Piping for Deck Gun
- Heavy Duty Aluminum Body & Sub Frame
- Ladder & Suction Hose Storage Thru Tank-Ground Accessible
- Four (4) Duel Wheel Well Air Bottle Compartments
- ROM Stain Finished Roll Up Doors
- Assortment of Adjustable Shelves, Roll Out Trays, Hinged Pac Trac Swing Out Tool Board, Zico Quic Index SCBA Bracket, & Duratile
- Krystal Lite-Strip LED Compartment Lights
- 1000 Gallon Poly Tank
- Floor Mounted Console with Switches, Radios, Siren, [...]
CUSTOM ENCLOSED TOP CONTROL PUMPER #2449
COON CREEK FIRE & RESCUE - COON VALLEY, WISCONSIN- November 30, 2021
- Not categorized
- Posted by R_Admin
- Comments Off on CUSTOM ENCLOSED TOP CONTROL PUMPER #2449
FEATURES:
- Spartan Metro Star MFD 24” Raised Roof with Bustle Back Cut Out
- Cummins 450 HP L9 Diesel Engine
- Allison EVS 3000 Transmission
- Occupant Advanced Protection System
- 24” Front Bumper Extension with Preconnected Front Suction
- Cam In View 360 Bird’s Eye View System
- Waterous CXVC 20 Single Stage 1500 GPM Pump
- Stainless Steel Enclosed Top Mount Pump Module
- FRC Pump Boss Pressure Governor
- Whelen LED Tank Level Gauges, Operator’s Panel and Three (3) Sides
- Stainless Steel Manifold and Plumbing
- 2.5” Discharges- One (1) Left Side, One (1) Right Side & Two (2) Rear and 3” Discharges-One (1) Right Side & One (1) Left side
- Three (3) Cartridge Lay Preconnects, Two (2) 1.5” & One (1) 2.5”
- 2.5” Gated Intakes, One (1) Each Side
- One (1) Front Suction Intake and One (1) Rear Suction Intake
- Waterous Aquis 3.0 Single Tank Foam System with 20 Gallon Integral Tank
- Fixed Monitor Piping with an Akron Model 3430 [...]
2000 GALLON BADGER TANKER #2439
MORRISVILLE FIRE DEPARTMENT - MORRISTOWN, VERMONT- November 30, 2021
- Not categorized
- Posted by R_Admin
- Comments Off on 2000 GALLON BADGER TANKER #2439
- Freightliner 114 SD Two Door Chassis
- Cummins L9 450 HP Engine
- Allison EVS 3000 Transmission
- Heavy Duty Aluminum Body & Sub Frame
- Rom Satin Finished Roll Up Doors
- 500 LB roll Out Trays
- Krystal-Lite LED Compartment Lights
- Progressive Dynamics Battery Charger with Kussmaul Auto Eject
- In House Air Inlet with Kussmaul Auto Eject
- 2000 Gallon Poly Tank
- Newton 10” Stainless Steel Swivel Dump-Electric Operated
- Whelen Warning Light Package
- Rub Rail LED Warning Lights & LED Ground Lights
- Whelen Electroinc Siren & Speaker
- Whelen 12 V LED Scene Lights
- Fold Da Tank & Suction Hose Storage -Thru Tank Slide in
- Armour Seal Body Undercoating
- NFPA Rear Chevron & Striping
- 9’ 9” Overall height
- 26’ 6” Overall length
- 200” Wheelbase
- 134.4” Cab to Axle
- 16,000 LB FAWR
- 30,000 LB RAWR
- 46,000 LB GVWR
CUSTOM 20’ HEAVY RESCUE #S774
LOGANSPORT FIRE DEPARTMENT - LOGANSPORT, INDIANA- November 6, 2021
- Not categorized
- Posted by R_Admin
- Comments Off on CUSTOM 20’ HEAVY RESCUE #S774
• Spartan ELFD Metro Star Chassis
• Cummins L9 450 HP Engine
• Allison 3000 EVS Transmission
• Occupant Advance Protection System
• Cab EMS Compartment Outside Access
• Fire Com Wireless Head Sets
• 21” Bumper Extension with Storage Compartment
• Front, Rear, & Side Hitch/Winch Assemblies
• Waterous CPK2-300 GPM PTO Pump, Located in L3 Compartment
• Pump Panel, FRC InControl Governor, Trident Air Primer in L3 Compartment
• Stainless Steel Manifold and Plumbing
• Two (2) Hanney Booster Reels, One (1) each side
• 300 Gallon Poly Tank
• Heavy Duty # 304 Stainless Steel Body
• Sub-Frame- Stainless Steel
• Three (3) Triple SCBA Wheel Well Bottle Compartments
• Five (5) Upper Coffin Storage Compartments with 21” Wide Recessed Walkway
• Ladder Storage Compartment in Upper Walkway
• Assortment of Pac Trac [...]
