CITY OF ROCHELLE FIRE DEPARTMENT
ROCHELLE, ILLINOIS
Technical Specs
• HME 1871-W MFDxL with 12" raised roof Chassis
• Cummins ISL9, 370-HP Diesel Engine
• Allison 3000 EVS Automatic Transmission
• Eight (8) man cab seating with five (5) SCBA seats
• Heavy Duty 3/16" Aluminum Body with painted ROM Roll Up Doors
• 750-Gallon Poly Tank with 30-Gallon foam tank
• Hale QMAX150, 1500-GPM Pump with pump operator's panel across top
• Four (4) 2 ½" Discharges, two (2) left side, one (1) right side and one (1) rear
• Two (2) 3" Discharges, one (1) right side and one (1) over pump for deck gun
• Two (2) 2 ½" Gated Suctions, one (1) each side
• 24" Front bumper extension with 5" front suction and preconnected hose
• One (1) 1 ½" Preconnect with hosewell, front bumper
• One (1) 5" Rear Suction
• Waterous Aquis 2.5 Foam system
• One (1) 2 ½" and two (2) 1 ½" Cartridge lay Preconnects, front of body
• EMS compartment with roll up door and shelves, cab
• Custom Pike Pole compartment for four (4) pike poles, under walkway
• Three (3) Triple bottle Air bottle compartments, two (2) right and one (1) left side
• One (1) Hinged pegboard tool board, left side
• Three (3) Vertical pull out tool boards, left side
• Three (3) walk-away air pack brackets, right side
• Zico Hydraulic Ladder Rack with suction hose and pike pole storage
• Kussmaul Auto Air on-board battery charger/air compressor with Auto Eject
• Federal Q2B mechanical Siren, front bumper
• One (1) GOLIGHT spotlight with remote control
• Smart Power 8000-watt Hydraulically driven Generator with 120-volt system
• One (1) Akron Electric cord reel with 150-ft of 10/3 cord and junction box
• Two (2) Extenda-Lite 120-volt LED Telescopic lights, one (1) each side
• Two (2) Extenda-Lite 120-volt LED Tripod lights, rear
• Whelen LED Scene Light and Warning Light Packages
• 10' 9" Overall height
• 34' Overall length
• 217" Wheelbase
• 157" Cab to Axle
• 20,000 FAWR
• 27,000 RAWR
• 47,000 GVWR
