Technical Specs
• Spartan Metro Star MFD 10" raised roof Chassis
• Cummins ISL9, 450-HP Diesel Engine
• Allison 3000 EVS Automatic Transmission
• Six (6) man cab Seating with five (5) SCBA seats
• Heavy Duty 3/16" Aluminum Body with ROM Roll Up Doors
• 24" Front bumper extension with 1 ½" Preconnect, hose well and 5" suction
• 1000-Gallon Poly Tank with 20-Gallon Foam tank
• One (1) 2 ½" Tank Fill, rear
• Darley PSM, 1500-GPM Pump
• Pump Operator's panel across top of apparatus
• Five (5) 2 ½" Discharges, two (2) left, one (1) right side and two (2) rear
• Two (2) 3" Discharges, one (1) right side and one (1) over pump for deck gun
• One (1) Akron Apollo "Hi-Riser" Deck Gun
• One (1) 2 ½" Gated Suction, left side
• Two (2) 1 ½" and one (1) 2 ½" Cartridge Lay Preconnect
• Foam Pro 2001 single tank Foam system
• Three (3) walkway compartments, one (1) each side and one (1) traverse
• Two (2) free floating running board hose wells, one (1) each side
• Two (2) Triple bottle Air bottle compartments, right side wheel well
• One (1) Fire Extinguisher storage compartment, left side wheel well
• Ladder/Pike pole storage compartment, right side with rear access
• Suction hose/Pike Pole storage compartment, left side with rear access
• Turtle Tile on floors and/or shelves and trays of compartments
• Federal Q2B Mechanical Siren, grill and two (2) Air horns, front bumper
• Progressive Dynamics on-board battery charger with Kussmaul Auto Eject
• Audiovox back-up Camera system with 7" color monitor
• Whelen Electronic Siren with 100-watt speaker
• Whelen and FRC Scene Light Packages
• Whelen LED Warning Light Package
• Diamond Grade Chevron pattern striping, rear
• 10' 10" Overall height
• 35' 8" Overall length
• 227" Wheelbase
• 173" Cab to Axle
• 20,000 FAWR
• 27,000 RAWR
• 47,000 GVWR
