Loraine Fire Protection
District
Loraine, IL
Technical Specs
• International 7400 4x2
Crew Cab Chassis
• International DT570 330 hp Diesel Engine
• Allison 3000 EVS Automatic Transmission
• Polished hub covers and lug nut covers
• Heavy Duty 3/16" Aluminum Body
• 1000 Gallon UPF Poly Tank IIE
• Hale QMID125 1250 GPM Stainless Steel Midship
Pump
• Top Mount Control Panel
• Hinged Pump Panels for Easy Access
• FoamLogix 2.1-A Foam Concentrate Proportioning
System
• One (1) Elkhart Stinger Monitor with 18"
pipe extension
• Two (2) 1-1/2" Cartridge Lay Preconnects
ahead of the pump
• Air bottle compartments in wheel wells
• Kussmaul Super Auto Eject Shoreline Connection
• Two (2) Havis-Shield Magnafire 12V 350W Floodlights
• Streamlight Lightbox Vehicle Mount System
• One (1) Norcold MFT-40 Refrigerator mounted
in L1 compartment
• Hydraulic ladder rack
• Suction hose storage under the tank "T"
on the right side for one (1) 10' section
• Suction hose storage for One (1) 10' section
on hydraulic ladder rack
• Pike Pole storage on ladder rack
• PowerArc Warning Light package
• 9'-8" Overall Height
• 35'-7" Overall Length
• 258" Wheelbase
• 147" Cab to Axle
• 14,000 FAWR
• 26,000 RAWR
• 40,000 GVWR
|
