Geneseo Fire Protection
District
Geneseo, Illinois
Technical Specs
• Peterbilt 340 2-Door Tandem
Chassis
• PACCAR PX-8, 360-HP Diesel Engine
• Allison 3000 EVS-P Automatic Transmission
• Heavy Duty 3/16" Aluminum Body
• UPF 3000-Gallon Poly Tank
• Hale QMAX150, 1500-GPM Pump
• Pump module side control
• Four (4) 2 ½" Discharges, two (2)
each side
• One (1) 3" Discharge, rear
• Two (2) 2 ½" Gated Suction, one (1)
each side
• Two (2) 1 ½" Mattydale Preconnects
and one (1) 2 ½" Mattydale Preconnect
• One (1) Hannay Booster Reel with 100-ft of 1"
hose, rear compartment
• Box style Doors
• One (1) Newton manual tank dump with 12"
flip chute, rear
• One (1) Ziamatic electric folding tank bracket,
left side
• Ladder brackets, right side
• Suction hose storage in the hose bed
• One (1) Wheel chock compartment, left side wheel
well
• One (1) Kussmaul Pump Plus 1200 air compressor/battery
charger
• One (1) Kussmaul Super Auto Eject 120-volt shoreline
• Two (2) Federal GHSCENE scene lights, rear
• Two (2) Akron Brass Extenda-Lite 12-volt 150-watt
telescopic lights, one (1) each side pump module
• Two (2) Grover Air Horns, one (1) each side of
hood
• Code-3 Electronic Siren with 100-watt Federal
speaker
• PowerArc Warning Light Package
• 10' Overall height
• 33' 11" Overall length
• 258" Wheelbase
• 188.9" Cab to Axle
• 16,000 FAWR
• 46,000 RAWR
• 62,000 GVWR
|
