City Of Norton Shores
Fire Department
Norton Shores, Michigan
Technical Specs
• International 4400 2-door
Chassis
• International MaxForce 9, 330-HP Diesel Engine
• Allison 3000EV Automatic Transmission
• Heavy Duty 3/16" Aluminum Body with Box
style doors and rear roll up door
• UPF 500-Gallon Rectangular Poly Tank with 10-gallon
foam tank
• Waterous CSU, 1500-GPM Pump
• Five (5) 2 ½" Discharges, two (2)
each side and one (1) rear
• One (1) 2 ½" Gated suction, left
side
• One 3" Discharge over pump compartment for
deck gun
• One (1) TFT XFC42 Deck gun with TFT Extend-A
Gun
• Two (2) 1 ½" Cartridge lay Preconnects
and one (1) 1 ½" front preconnect
• Foam Pro 1600 foam system
• Front bumper hose well with capacity for 100-ft.
of 1 ¾" hose
• One (1) Kussmaul Air eject
• One (1) David Clark Head set system with three
(3) positions
• Four (4) Dual Air bottle compartments, two (2)
each side
• Four (4) Upper storage compartments with lift
up lids, two (2) each side roof
• One (1) Backboard/Stokes Basket rack, top of
rear compartment with side access
• Six (6) FlameFighter Walk-away Air pak brackets,
three (3) each side
• Ladder and Pike pole storage under hose bed with
rear access
• Vanner 30-10, 110-volt on board battery charger/conditioner
• One (1) Kussmaul Super auto eject 120-volt shoreline
• Four (4) Federal GHSCENE large scene lights,
one (1) each side and two (2) rear
• One (1) Code-3 NightProbe remote controlled spot
light, cab roof
• Onan 10-kW hydraulically driven Generator
• One (1) Akron electric cord reel with 150-ft.
of 10/3 cord and lighted junction box
• Two (2) Extenda-Lite 120-volt 500-watt telescopic
lights, rear
• Two (2) Grover Air horns and One (1) Federal
Q2B Siren, front bumper
• Code-3 Electronic Siren with 100-watt Federal
speaker
• Code-3 Warning Light Package
• 9' 8" Overall height
• 31' 5" Overall length
• 213" Wheelbase
• 145.9" Cab to Axle
• 12,000 FAWR
• 26,000 RAWR
• 38,000 GVWR
|
