Mount Pleasant Fire
Department
Mount Pleasant, Iowa
Technical Specs
• Spartan Advantage-Big
Easy 10" raised roof Chassis
• Cummins ISC-330, 330-HP Diesel Engine
• Allison 3000EVP Automatic Transmission
• Heavy Duty 3/16" Aluminum Body
• UPF 1000-Gallon T-Type Poly Tank
• Hale QMAX-150, 1500-GPM Pump
• Top Mount Pump Controls
• Five (5) 2 ½" Discharges, Two (2)
left side, One (1) right and two (2) rear
• One (1) 3" Discharge, right side
• Two (2) 2 ½" Gated Suction, right
side
• Elkhart Portable Elk-O-Lite Deck Gun
• Two (2) 1 ½" Cartridge Lay Preconnects
• One (1) 1 ½" Preconnect in bumper
extension
• Box Style Compartment Doors
• Nine (9) FlameFighter Walk-away Air Pak Brackets,
five (5) left side and four (4) right
• Vanner 30-10, 110-volt automatic battery charger/conditioner
• Two (2) Unity Deck lights, rear
• Onan 8-kW Hydraulically driven Generator
• Two (2) Hannay 120-volt Electric cord reels in
rear compartment
• Two (2) Extenda Light 120-volt 1000-watt telescopic
lights
• Two (2) Extenda Light 120-volt 500-watt telescopic
lights, rear
• Code-3 Electronic Siren with Federal speaker
• Hadley Dual Stuttertone 24" Air Horns
• Whelen Warning light Package
• 10' Overall height
• 33' 6" Overall length
• 210" Wheelbase
• 156" Cab to Axle
• 18,000 FAWR
• 27,000 RAWR
• 45,000 GVWR
|
