Limestone Township Fire
Protection District
Peoria, Illinois
Technical Specs
• HME 1871P2 MFDxl Chassis
• Cummins ISL-400 HP Engine
• Allison 3000EVS Automatic Transmission
• Heavy Duty 3/16" Aluminum Body
• 1000 Gallon UPF Poly Tank
• Left Side Control Pump Panel
• Waterous CMU 1500 GPM pump
• 5" Front Suction
• Recess mounted Federal Q2B siren
• Akron Apollo Deck Gun
• Two (2) 1-1/2" Cartridge Lay Preconnects
• Wheelwell air bottle compartments: two (2)
right side; one (1) left side
• Robinson ROM roll-up doors with satin finish
• Class-1 Krystal-Lite tube compartment lighting
• Transverse storage compartment for backboards
and long handled tools in L3; R3 compartments above
rear dump
• Five (5) adjustable shelves
• One (1) roll-out tray with 600# capacity
• Whelen LED Strip-Lite tank level gauge
• One (1) 2-1/2" Fireman's Friend rear tank
fill
• One (1) square Newton 10" dump, manually
controlled
• PowerArc recess mounted LED Powerstick
• PowerArc warning light package
• Two (2) Code-3 scene lights, one (1) each side
of pump module
• Two (2) Code-3 scene lights, one (1) each side
at rear of apparatus compartments
• ONAN 6Kw Hydraulic generator
• Hannay electric cord reel w/ 200' of 12/3 cord
• Two (2) Extenda Light 750W Quartz "Beta"
telescopic flood lights, one (1) each side at rear of
chassis cab
• Ladder, pike pole and suction hose storage
compartment under hosebed, accessible from rear
• Aluminum treadplate EMS compartment installed
in chassis cab
• 9' Overall Height
• 32'-6" Overall Length
• 200" Wheelbase
• 140" Cab-to-Axle
• 18,000 FAWR
• 27,000 RAWR
• 45,000 GVWR
|
