Knoxville Community
Fire
Protection District
Knoxville, Illinois
Technical Specs
• International 7400,
4-Door Chassis
• International DT570, 330-HP Diesel Engine
• Allison 3000EVS Automatic Transmission
• Heavy Duty 3/16" Aluminum Body
• UPF 1750 Gallon T-type Poly Tank
• Hale QMAX150, 1500-GPM Pump
• Top Mount Pump Controls
• ROM Roll Up Doors
• Five (5) 2 ½" discharges, two (2)
each side and one (1) rear
• One (1) 2 ½" Gated suction, left
side
• Two (2) 1 ½" cartridge lay preconnects
• Four (4) Air bottle compartments, Two (2) each
side in wheel wells
• Newton tank Dump with 36" extension at
rear
• Kussmaul Pump-Plus 1200 air compressor/battery
charger
• Kussmaul super auto eject 120-volt shoreline
• Ziamatic electrically controlled ladder rack
• Two (2) Whelen large scene lights, each side
rear
• Two (2) Grover Air horns, one (1) each side
of hood
• Code-3 Electronic Siren with Federal speaker
• PowerArc Warning light package
• 9' 10" Overall height
• 33' 11" Overall length
• 278" Wheelbase
• 167" Cab to Axle
• 14,000 FAWR
• 30,000 RAWR
• 44,000 GVWR
|
