FRANKLIN GROVE FIRE
PROTECTION DISTRICT
Technical Specs
• Freightliner M2 2-door
chassis
• Mercedes Benz 210 HP Diesel Engine
• Allison 2000 EVP Automatic Transmission
• Backboard/Cascade Bottle Storage in the L1/R1
transverse compartment
• Two (2) adjustable shelves and one (1) roll out
tray in the L2 compartment
• One (1) roll out tray in the L3 compartment
• Two (2) adjustable shelves and one (1) roll out
tray in the L4 compartment
• 4-bottle 4500 PSI cascade system with fill panel
located in R1 compartment
• Two (2) adjustable shelves and 12 bottle air
bottle rack in the R2 compartment
• One (1) Zico Quik-Index with 4 air pack brackets
mounted on roll out tray in the R3 compartment
• Two (2) Vertical pull out boards in the R4
compartment
• Rescue tool storage in the rear compartment
on one (1) roll out tray
• Ice sled storage compartment above the
rear compartment
• 9' - 0" Overall Height
• 28' - 4" Overall Length
• 175" Wheelbase
• 108.6" Cab to Axle
• 8,000 FAWR
• 15,000 RAWR
• 23,000 GVWR
|
