Fox Lake Fire Department
Fox Lake, Illinois
Technical Specs
• Spartan Advantage-MFD
20" Raised roof Chassis
• Cummins ISL 350, 350HP Diesel Engine
• Allison 3000 EVP Automatic Transmission
• Heavy Duty 12 gauge stainless steel Body
• UPF 1000 gallon T-type Poly Tank
• Hale QMAX 150, 1500 GPM Pump
• Enclosed top mount pump controls
• Rom Roll up Doors
• Three (3) air bottle compartments two (2) right
side and one (1) left
• Akron Apollo monitor deck gun with automatic
nozzle
• Three (3) cartridge lay Preconnects two (2) 1
¾" and one (1) 2 ½"
• Two (2) Hannay dual hydraulic hose reels in rear
compartment
• Two (2) swing out tool boards, one (1) each side
• Hannay electric booster reel upper rear
• Kussmaul Air Eject adjacent to Driver door
• Kussmaul super auto eject 120 volt shoreline
• Kussmaul 110 volt automatic battery charger/conditioner
• Onan 10 kW hydraulically driven Generator
• Two (2) Hannay 120 volt electric cord reels one
each side
• Cascade system with four (4) 4500 psi bottles
• Two (2) Hannay air hose reels one each side
• Zico hydraulic ladder rack right side
• Two (2) Extenda-lite 650 watt telescopic lights
• Beta 4000, 500 watt light, cab mounted
• Two (2) Extenda-lite telescopic tripod flood
lights rear
• Federal Q2B Siren
• Code-3 Upper warning package
• Whelen Lower warning light package
• 12" chrome plated brass bell above the front
grill electrically controlled
• 10' 6" Overall height
• 32' 10" Overall length
• 205" Wheelbase
• 151" Cab to Axle
• 20,000 FAWR
• 31,000 RAWR
• 51,000 GVWR
|
