El Paso Fire Protection
District
El Paso, Illinois
Technical Specs
• HME 1871P2 MFDxl 12"
raised roof cab Chassis
• Cummins ISC-330 HP diesel engine
• Allison 3000EVS Automatic Transmission
• Heavy Duty 3/16" Aluminum Body
• UPF 1000 Gallon Poly Tank
• Hale QFLO 1250 gpm Pump
• Rear mounted Ramsey 8,000# winch
• 5" Rear suction
• Akron Apollo Deck Gun
• FoamLogix 2.1A Foam system with 20 gallon integral
foam cell.
• Two (2) 1-1/2" Cartridge lay preconnects
• 1-1/2" bumper extension preconnect
• Federal Q2B mechanical siren on gravelshield
• Akron valving
• Air bottle compartments: one (1) left side; two
(2) right side wheelwell assemblies
• Robinson ROM roll-up doors with satin finish
• Class-1 Krystal-Lite tube compartment lighting
• Kussmaul Pump Plus air compressor/ battery charger/conditioner
sys w/ Super Auto Eject
• PowerArc 42" LED surface mounted arrowstick
• PowerArc warning light package
• Federal GHSCENE lights, one (1) each side pump
module
• FRC 120V Optimum 650W HIR, OPA800-HR65 brow light
on cab
• Class-1 ESKEY multiplex electrical system
• Onan 6 Kw hydraulic generator
• Hannay electric cord reel in rear compartment
w/ 200' of 12/3 cord
• Two (2) Extenda Lite 750W Beta telescopic lights
on back of chassis cab
• Two (2) 500W recessed Fire Research FCA200 flood
lights one (1) each side rear of body
• Two (2) bottle cascade system w/ 2 bank fill
panel
• Hydraulic ladder rack right side
• Suction hose storage: one (1) on hydraulic ladder
rack; one (1) in compartment under tank "T"
• 9'-8" Overall Height
• 33'-2" Overall Length
• 206" Wheelbase
• 146" Cab to Axle
• 18,000 FAWR
• 27,000 RAWR
• 45,000 GVWR
|
