Deland Community Fire
Protection District
Deland, Illinois
Technical Specs
• International 7400 2-Door
Chassis
• International Maxx Force 9 GDT330, 330-HP Diesel
Engine
• Allison 3000EVS P Automatic Transmission
• Heavy Duty 3/16" Aluminum Body
• UPF 1250-Gallon Poly Tank
• Hale HFM100, 1000-GPM Pump
• Front Operators Pump Panel, left side in bumper
extension decking
• Four (4) 2 ½" Discharges located
on the pump head
• Two (2) 1" Boosters with 10-ft.of hose,
front bumper extension
• One (1) 1 ½" Preconnect, rear in
hose bed
• One (1) 2 ½" Gated Suction, right
side
• One (1) Hannay Electric Booster Reel, rear
compartment
• ROM Roll Up Doors
• Front Bumper Extension with Grass Guard railing
• One (1) set of Ladder brackets with attic ladder
bracket, right side
• Two (2) Suction Hose gutters for 10-ft. length,
one (1) each side
• Manual Battery recharge receptacle
• Two (2) Unity Deck Lights, rear
• Onan 6-kW Hydraulically driven Generator
• Two (2) 120-volt exterior outlets, one (1)
each side
• Two (2) Akron Brass Extenda-Light 120-volt
750-watt telescopic lights, one (1) each side
• One (1) Akron Brass Extenda-light 120-volt
750-watt tripod light, rear
• Code-3 Electronic Siren with 100-watt Federal
speaker
• PowerArc Warning Light Package
• 10' 0" Overall height
• 28' 5" Overall length
• 175" Wheelbase
• 107.9" Cab to Axle
• 14,000 FAWR
• 26,000 RAWR
• 40,000 GVWR
|
