Calamus Volunteer Fire
Department
Calamus, Iowa
Technical Specs
• Peterbilt 340, 2-Door
Chassis
• Cummins ISC 330, 330-HP Diesel Engine
• Allison 3000 EV Automatic Transmission
• Heavy Duty 3/16" Aluminum Body
• UPF 1000-Gallon Poly Tank
• Hale QPAK 100, 1000-GPM Pump
• Four (4) 2 ½" Discharges, two (2)
left side, one (1) right side and one (1) rear
• Two (2) 2 ½" Gated suction, one
(1) each side
• Two (2) 1 ½" Cartridge Lay Preconnects
with Hypalon cover
• Four (4) Air Bottle compartments, two (2) each
side
• ROM Roll Up Doors
• Four (4) FlameFighter Walk-away air pak brackets,
left side compartment
• One (1) Hannay Electric Booster Reel with 100'
of 1" hose, rear compartment
• Ladder brackets, right side
• 110-volt Vanner 30-10 Automatic battery charger/conditioner
• 120-volt manual Shoreline
• Four (4) Whelen large Scene lights, one (1)
each side and two (2) rear
• Two (2) Unity Deck lights, rear
• Two (2) Havis Shield Magnafire 12-volt Floodlights,
one (1) each side
• Federal Electronic Siren with 100-watt Federal
speaker
• Code-3 Upper Warning light Package
• PowerArc Lower Warning light Package
• Overall height
• Overall length
• 216" Wheelbase
• 146.2" Cab to Axle
• 12,000 FAWR
• 26,000 RAWR
• 38,000 GVWR
|
