Arlington Fire Protection
District
Arlington, Illinois
Technical Specs
• Peterbilt 335, 2-Door
Chassis
• Caterpillar C7, 330-HP Diesel Engine
• Allison 3000 EVS Automatic Transmission
• Heavy Duty 3/16" Aluminum Body
• UPF 1000-Gallon T-Type Poly Tank with 20-Gallon
Foam tank
• Waterous CSC10E, 1250-GPM Pump
• Top Mount Pump controls
• ROM Roll Up Doors
• Waterous/Pneumax 80 CAFS system
• Five (5) 2 ½" Discharges, Two (2)
each side and one (1) rear
• One (1) 2 ½" Gated suction, left
side
• Two (2) 1 ½' Cartridge Lay Preconnects
• Four (4) Air Bottle Compartments, two (2) each
side wheel wells
• Akron Apollo Deck Gun
• Vanner 30-10 Automatic charger/conditioner
• Kussmaul Super Auto eject 120-volt Shoreline
• Attic ladder bracket with extension and roof
ladder brackets
• Two (2) Havis Shield Magnafire 12-volt Floodlights,
one (1) each side
• Two (2) Unity deck lights, rear
• Two (2) Grover Air horns, one (1) each side
of hood
• Federal Electronic siren with Federal speaker
• PowerArc Warning light Package
• 9' 10" Overall height
• 29' 10" Overall length
• 216" Wheelbase
• 146.2" Cab to Axle
• 12,000 FAWR
• 26,000 RAWR
• 38,000 GVWR
|
